Flow Measurement

Brand: Krohne

High accuracy (±0.05% flat), for cryogenic to high temperature media (-200…+400°C / -328…+752°F); maintains operation over a wide range of gas fractions and complex flow conditions (EGMTM)
SIL 2/3; CT: OIML R117, R137, MI-005, MI-002; API, AGA; hygienic certifications
Flange: DN10…300 / ½…12", max. PN 160 / ASME Cl 1500
3 x 4…20 mA, HART®7, Modbus, FF, Profibus-PA/DP, PROFINET, EtherNet/IP™, Bluetooth®

Qty: - +

Twin bent tube design
Entrained Gas Management (EGM^TM): maintains operation with air or gas entrainments in the medium
Available with Ethernet-APL for hazardous areas
The world's first Coriolis mass flowmeter on the market allowing secure wireless access via Bluetooth^® or remotely via HART^® in safety-related applications
Device commissioning, verification, diagnostics and monitoring via a secure wireless Bluetooth^® connection (<20 m / 65.6 ft)
SIL 2/3 certified up to DN200 / 8″
Partial proof test possible with PTC (Proof Test Coverage) of up to 82%
Fast and completely digital signal processing
Integrated temperature measurement
Optimised flow splitter for minimum pressure loss
High accuracy mass, density and volume flow measurement (optional ±0.05% of MV)
Highest OIML accuracy class of 0.3 for custody transfer (CT)
Extensive sensor and process diagnostics (incl. NE 107)
Available in three different sensor materials (incl. Duplex and alloy 22)
Many options (heat tracing, purge port etc.)
Self draining when mounted vertically
No crosstalk: resistant to installation and process effects
On-site verification of flowmeter with OPTICHECK service tool possible
