Electromagnetic flowmeter for safety instrumented systems (SIS) and high-accuracy requirements Certified for safety applications up to SIL 2/3, with automated partial proof test capability for extended proof test intervals Best-in-class diagnostic test interval incl. fault response time of only 2 minutes SIL 2/3 up to DN600 / 24"; non-SIL up to DN2000 / 80" (larger on request) Pulse, frequency, status, 4…20 mA, HART®7

Electromagnetic flowmeter for advanced process and custody transfer (CT) applications High accuracy (±0.2%), certified for custody transfer For low conductivity media (>1 μS/cm) and high solid contents (≤70%) Flange: DN2.5…3000 / ⅒…120", max. PN40 / ASME Cl 600 (higher on request) 3 x 4…20 mA, HART®,Modbus, FF, Profibus-PA/DP, PROFINET

Electromagnetic flowmeter for advanced process and master meter applications Highest accuracy (±0.15%), with ceramic tube for aggressive and abrasive liquids (≤70% solid content) up to +180°C / +356°F CT: OIML R117, MI-005 etc. Flange: DN15…300 / ½…12", max. PN40 / ASME Cl 300; Sandwich: DN2.5...100 / ⅒...4" 3 x 4…20 mA, HART®, Modbus, FF, Profibus-PA/DP, PROFINET

Electromagnetic flowmeter for low conductivity liquids (≥0.05 μS/cm) Ceramic tube with non-wetted electrodes for extremely adhesive and abrasive media Hygienic and vacuum resistant Flange or wafer/sandwich version: DN25…100 / 1…4", max. PN40 / ASME Cl 300 3 x 4…20 mA, HART®, Modbus, FF, Profibus-PA/DP, PROFINET

Electromagnetic flowmeter for OEM applications, dosing systems and compact skids Economical flow measurement of liquids (≥5 μS/cm) with solid content (≤70%) -25…+120°C / -13…+248°F Wafer-style design: DN10…150 / ⅜…6", max. PN40 / ASME Cl 300 3 x 4…20 mA, HART®, Modbus, FF, Profibus-PA/DP, PROFINET

Electromagnetic flowmeter for advanced water and wastewater applications High accuracy (±0.2%), with CT approvals (OIML R49, MI-001) 0D/0D installation acc. to MID MI-001 and OIML R49 accuracy class 1 Flange: DN25…3000 / 1…120", max. PN40 / ASME Cl 300 3 x 4…20 mA, HART®, Modbus, FF, Profibus-PA/DP, PROFINET

Electromagnetic flowmeter for nuclear applications Designed and tested for industrial nuclear environments With resistant ETFE or PFA liner materials Flange: DN25…1000 / 1…40" 3 x 4…20 mA, HART®, Modbus, FF, Profibus-PA/DP, PROFINET

Electromagnetic flowmeter for nuclear applications Designed and tested for industrial nuclear environments With high-tech ceramic tube for very aggressive and abrasive fluids Space-saving wafer design: DN2.5…100 / 1⁄10…4" 3 x 4…20 mA, HART®, Modbus, FF, Profibus-PA/DP, PROFINET

Electromagnetic flowmeter for applications with partially filled pipes With integrated capacitive level measurement for flow measurement of water and wastewater (≥10% pipe fill level) Accurate (±1%) and cost-saving alternative to open channel systems Flange: DN200…1600 / 8…64" 3 x 4…20 mA, pulse, HART®, Modbus, PROFINET

Enhanced signal conditioning circuitry provides excellent noise and spike immunity High stable and repeatable output with ±0.5% of rate accuracy Minimum process fluid conductivity requirement of 10μS/cm provides maximum applicability Electrode Status Diagnostic function diagnoses empty pipe condition or electrode scaling Available in wafer of flanged designs Both Integral and Remote configurations are available for maximum flexibility Detector sizes from 0.1″ to 8″ (2.5 to 200mm) are available

Flexible Digital Communications with HART, DE and Foundation Fieldbus Protocols Intuitive, versatile operator interface with large characters and back-lit LCD dispaly Optional I/O capability for dual range selection input, counter status output and many more! Excelent noise immunity for reliable process control Optional “Fast Response” model for short-run batch applications Averaging function for pulsating flow applications. MagneW™ is a trademark of Azbil Corporation

Exclusive high quality lining technology and a special “mirror’fiish” PFA lining offers higher anti-adhession properties than competitive models Lining uses only pure white PFA with no additives Lining is reinforced with stainless mesh and divetailed to flow body providing durablity and long service life in the most difficult applications Flanged detectors available in line sizes from 0.1 inch to 44 inch (2.5 to 1100mm) Wafer style detectors available in line sizes from 0.1 inch to 8 inch (2.5 to 200mm) Field-replaceable electrodes are avialable as standard feature on most models 0.1 in through 8 inch detectors feature all-welded stainless steel construction MagneW™ is a trademark of Azbil Corporation

Exclusive high quality lining technology and a special “mirror’fiish” PFA lining offers higher anti-adhession properties than competitive models Lining uses only pure white PFA with no additives Lining is reinforced with stainless mesh and divetailed to flow body providing durablity and long service life in the most difficult applications Flanged detectors available in line sizes from 0.1 inch to 16 inch (2.5 to 400mm) Wafer style detectors available in line sizes from 0.1 inch to 8 inch (2.5 to 200mm) Field-replaceable electrodes are avialable as standard feature on most models 0.1 in through 8 inch detectors feature all-welded stainless steel construction MagneW™ is a trademark of Azbil Corporation

The Only Hot Tap Full Profile Insertion Mag Meter The FPI electromag flow meter is ideal for capital or maintenance projects, retrofits and sites that have never before been metered. The unique combination of accuracy, ease of installation and total cost savings make the FPI Mag the perfect choice for a wide range of Municipal and Industrial Applications. McCrometer’s multi-electrode design and unique operating principle, delivers accuracy unmatched by other insertion meters and rivals the performance of full-bore mag meters. This next generation of insertion technology makes flow monitoring efforts simple and precise.
