Valves

Mosite A20N

The Mosites A20N Butterfly Valve was developed in response to market demand for a high cycle butterfly valve. Reduced torque and low profile disc increases the A20N cycle capabilities and economizes your actuation cost. Uniquely suited for applications involving continuous cycling, the Mosites A20N Butterfly Valve provides reliable service in flow control applications. Incorporating the same features as the A20, the A20N meets API 609 and MSS-SP 67 laying length (face-to- face) dimensions for quick replacement of standard butterfly valves.

- +

Mosite C30

The Mosites C30 Butterfly Valve was developed to fill an industry need for a high cycle, fully elastomer lined butterfly valve. If your processes involve chemicals, slurries, water, air or vapors, the C30 can solve your control problems. It is available in the standard Mosites face to face dimension.

- +

Mosite C30N

The Mosites C30N Butterfly Valve was developed to fill an industry need for a high cycle, fully elastomer lined butterfly valve. If your processes involve chemicals, slurries, water, air or vapors, the C30N can solve your control problems. Incorporating the same unique features as the C30, the C30N meets API 609 and MSS-SP 67 laying length (face-to-face) dimensions for quick replacement of standard butterfly valves.

- +

Swissfluid SCP Plug Valve

½" – 6" RP (red. port) SCP Cylindrical Plug Valves are ideally suited for Shut-off, Flow Control and Throttling of corrosive, abrasive or even toxic process media in either liquid or gaseous state.
Two-piece body made of cast steel, top entry
Dynamic, maintenance-free shaft sealing acc. to TA-Luft
Cavity-free design, low torque, full port
One-piece cylinder/shaft, blow out proof, core of SS Duplex
Rated breaking point outside of valve
Cylinder options such as V-port, with pressure relief hole
Easy maintenance at severe service conditions
ISO top flange for direct mounting of pneum. quarter turn actuators

- +

Swissfluid SDV Diaphragm Valve

½" – 8" SDV Diaphragm Valves are ideally suited for Shut-off, Flow Control and Throttling of corrosive process media in either liquid or gaseous state.
Proven weir type valve body made of cast steel
Cavity-free design
Installation in any attitude (self-draining)
Force limiting device protecting diaphragm
Yellow sight indicator showing actual position of diaphragm
Easy replacement of components on site

- +

Swissfluid SBC Ball Check Valve

NPS ½ˮ–6ˮ SBC Ball Check Valves are ideally suited as reliable non-return flow control for liquid process media.
Horizontal or vertical installation
Large safety glass plates
Solid or hollow balls
Quad ball guide
For liquids, gases and steam
Bubble tight at low differential pressure

- +

Swissfluid SSC Swing Check Valve

NPS 1½ˮ–24ˮ Suited for safe non-return flow control of corrosive fluidic media to be handled in process piping systems.
Wafer-style body, two- and three-piece, DIN/ANSI combined
Centering lugs for safe installation
Tilted disc (to shut by gravity even when pipe isn't completely level)
Self-retaining disc, no counter flanges needed to hold the disc in place
Horizontal or vertical installation
Integrated sealing lip (to seal at low differential pressures)

- +

Swissfluid SSB Sampling Ball Valves

½” – 6”, full port for safe and representative sampling of aggressive or even toxic liquids from pressurized pipelines without any process interruptions.
Body lined or fully made of stainless steel
Easy and safe operation, nonpressurized sampling
Horizontal or vertical installation
Defined sampling volume
Extraction of smallest samples
Full port design, easy cleaning (piggable)
Sampling from vacuum systems
Interruption of system pressure through pressure lock
Simple automation with time control
Sampling unit for installation onto vessels

- +

Swissfluid SIV Inline Sampling Valves

½" – 6" Inline Valves for safe and representative sampling of corrosive, aggressive or even toxic media from pipe- lines, pressurized or at vacuum conditions – without process interruptions.
Bodies wafer- style and flanged version
Easy, safe operation
Dead-space-free design
Installation in any given position
Maintenance-free stuffing box or bellows seal acc. to TA-Luft
Large outlet bore, adjustable spindle stroke
Leakage control connection
Adapter with quick clamp system
Corrosion-resistant materials as well as various alloys
Wide selection of options and accessories
Combinable with closed sampling systems

- +

Swissfluid SSO-C Combined Sampling Systems

In combination with the SIV, inline sampling is guaranteed. In addi- tion, the sample can be drawn over the loop (also gaseous). The closed system allows the safe drawing of an extremely re- presentative sample. In addition, handling and rinsing is very simple.

- +

Swissfluid SSO-S Sampling Station

The sample is drawn over a needle adapter by septum. The PP safety cabinet offers additional full protection for the operator, who can operate the sampling station from outside.

- +

Swissfluid SSO-P Sampling Systems

Available in different variations according to customer require- ments. This version allows several samples to be taken from different sampling points. The quick-closing locking mechanism allows the sample cylinder to be removed safely and quickly. The system can easily be switched to purge with ﬂ ow indicator during the whole process.

- +
